LED display module TM080TDGP01

TFT LCDLCD/ISTNtouch screen

A TFT LCD has a liquid crystal layer between a glass substrate formed with TFTs and transparent pixel electrodes and another glass substrate with a color filter (RGB) and transparent counter electrodes. Each pixel in an active matrix is paired with a transistor that includes capacitor which gives each sub-pixel the ability to retain its charge, instead of requiring an electrical charge sent each time it needed to be changed. This means that TFT LCD displays are more responsive. • - Size :8 inch • - Resolution : 1024x768 • - Interface : LVDS • - Voltage : 5V • - Temperature : -20°C ~ 70°C • - Outline : 183. 43 × 138.35 × 3.75(mm) • - Active Area : 162.05 × 121.54(mm) TM080TDGP01 from Tianma is a 8 inches TFT LCD display module,1024(RGB)x768 resolution. It is a transmissive TFT LCD with white LED backlight, wide viewing angle.
