CNC turning center LA series
2-axis3-axisA2-6

CNC turning center - LA series - Toyoda Machine Works - 2-axis / 3-axis / A2-6
CNC turning center - LA series - Toyoda Machine Works - 2-axis / 3-axis / A2-6
CNC turning center - LA series - Toyoda Machine Works - 2-axis / 3-axis / A2-6 - image - 2
CNC turning center - LA series - Toyoda Machine Works - 2-axis / 3-axis / A2-6 - image - 3
Add to favorites
Compare this product


Characteristics

Control type
CNC
Number of axes
2-axis, 3-axis
Spindle mount
A2-6
Performance
high-performance, high-speed
Diameter

470 mm
(18.5 in)

Spindle speed

4,000 rpm
(25,132.741 rad.min-1)

Maximum cutting diameter

250 mm, 320 mm
(10 in, 13 in)

Maximum cutting length

284 mm, 300 mm, 584 mm, 600 mm
(11 in, 12 in, 23 in, 24 in)

Bar capacity

52 mm
(2 in)

Axe X

175 mm
(7 in)

Axe Z

375 mm
(15 in)

Nominal power

7.5 kW, 11 kW
(10.2 hp, 15 hp)

Description

The LA model is designed with a high performance spindle and modulized structure with optional live tooling. 2 axes + C axis Gear Driven spindle Box Guideway LA-200 Standard turning center Max. turning length: 11.8" (300 mm) Max. turning Diameter: 12.6" (320 mm) LA-200L Turning center with long bed Max. turning length: 23.6" (600 mm) Max. turning Diameter: 12.6" (320 mm) LA-200M Turning center with milling capabilities Max. turning length: 11.2" (284 mm) Max. turning Diameter: 9.8" (250 mm) LA-200ML Turning center with longer bed and milling capabilities Max. turning length: 23" (584 mm) Max. turning Diameter: 9.8" (250 mm)

VIDEO
