Magnetic drill HU-40-TSIelectric
Add to favorites
Compare this product
Characteristics
- Type
- magnetic
- Power source
- electric
- Rotational speed
Max.: 1,450 rpm
(9,110.6 rad.min-1)Min.: 50 rpm
(314.2 rad.min-1)
Description
Automatic gear drill.
Features:
- Rolled iron steering wheel.
- Height adjustable table with screw.
- Rotary table.
- Expeller.
- Electro-magnetic clutch.
- Right / left drill bit.
- 2 speed motor.
- Zero voltage protection.
OPTIONS:
PACKAGING AND DIMENSIONS:
730x560x2220 mm (460 Kg)
Standard packaging
2.0 Hp motor
Drill capacity 40 mm
Morse cone MT4
Speeds 50-1450 rpm
Distance axis-column 350 mm
Distance axis-table 780 mm
Distance axis-base 1320 mm
Diameter column 150 mm
Dimensions table 560 x 560 mm
Dimensions base 730 x 500 mm
Slots 2 diagonally
Net weight 460 kg
Dimensions 730x560x2220 mm
Shaft travel 180 mm
