- Steel structure to give rigidity and stability, consolidated with special treatment against vibrations and temperature changes.
- Anti-torsion bar.
- Integrated hydraulic transmission system, equipped with several tanks.
- Electrically adjustable rear stop with fine adjustment and digital display.
- Mechanical adjustment of the tranche independently of the cylinder to allow the superior closing.
- System of descending work of fixed table and mobile upper trancha.
- Motorized penetration stop with Numeric Control that controls the 2 preselector stops of the rear stop and the vertical penetration stop with 99 programs and 20 cycles in each program.
- Top with sliding fingers on high precision skates.
- Bimanual control, with emergency stop.
- Gooseneck on all models.
OPTIONS:
*AKAS - SECURITY SYSTEM
* DEPENDING ON STOCK, THE MACHINE CAN BE IN BLUE OR GRAY COLORS
PACKAGING AND DIMENSIONS:
5100x2245x4210 mm (29000 Kg)
Standard packaging
Folding force 300 Tn
Folding length5000 mm
Distance between studs3820 mm
Gooseneck400 mm
Carrera250 mm
Descent speed60 mm / sec
Working speed5 mm / sec
Return speed48 mm / sec
Board table distance560 mm / sec
Motor20.00 Hp
