Band saw HU-340/500-SA

for steelsemi-automaticwith cooling system

Semiautomatic bandsaw Hydraulic belt-saw for cutting up to 60º left and 60º right.Band sawing machine made with the highest strength and reliability. Exact cutting by means of hard metal guides, right and left cutting until 60º, degrees digital display and refrigeration by air-oil microspraying. Caracteristics: Band sawing machine made with the highest strength and reliability. Exact cutting by means of hard metal guides, right and left cutting until 60º, degrees digital display and refrigeration by air-oil microspraying. - CE rules. - Microsprayed refrigeration unit. - Electronic speed variator 26/86 - Tension and belt breaking control. - Cutting pressure adjustment. - Clamp hydraulic. OPTIONAL EQUIPMENT: •Hydraulic / Manual vertical Clamp. •Roller-Tracking for heavy loaded material. •Manual, digital and Self-positionning Roller-Tracking with measurement Systems. •Cutting laser Light. PACKAGING & DIMENSIONS: •830x2450x1300 mm (950 Kg) •Wooden palet Belt dimensions 4380x34x1,1 mm Motor 4.0 HP Cutting speed 26 - 86 mt/min Working height 750 mm Coolant pump 0,16 HP Sound level 70 db
