CNC automatic lathe SS267 series
5-axisdrillingY-axis

CNC automatic lathe - SS267 series - Tsugami - 5-axis / drilling / Y-axis
CNC automatic lathe - SS267 series - Tsugami - 5-axis / drilling / Y-axis
CNC automatic lathe - SS267 series - Tsugami - 5-axis / drilling / Y-axis - image - 2
Add to favorites
Compare this product


Characteristics

Control type
CNC
Number of axes
5-axis
Applications
drilling
Other characteristics
Y-axis
Associated function
milling
Diameter

26 mm, 32 mm
(1.02 in, 1.26 in)

Spindle speed

7,000 rpm, 8,000 rpm, 10,000 rpm
(43,982.297 rad.min-1, 50,265.482 rad.min-1, 62,831.853 rad.min-1)

Rapids on X

24,000 mm/min
(16 in/s)

Nominal power

3.7 kW, 5.5 kW
(5 hp, 7.5 hp)

Overall lenght

1,270 mm
(50 in)

Overall width

2,630 mm
(104 in)

Overall height

2,010 mm
(79 in)

Weight

4,000 kg
(8,818 lb)

Description

SWISS TURN equipped with B-axis enables advanced complex machining. ●Live tool of B-axis tool post can machine freely at any angle. ●Modular type B-axis tool post (option) allows whirling head and multiplied live tools to be added. ●By multiplied tool spindle (option) on back tool post, small hole drilling is achieved with high efficiency. ●Thanks to the thermal displacement compensation, the long-term stable production is realized. ●Automatic programming software is provided as standard.
