Fixed-wing UAV for industrial applicationsmonitoringautonomous
Add to favorites
Compare this product
Characteristics
- Type
- fixed-wing
- Applications
- for industrial applications, monitoring
- Other characteristics
- autonomous
- Endurance
24 h
Description
T/O & Landing : Automatic Take-off & Landing
Mission Payload : EO / IR Camera
Flight Mode : Fully Autonomous Flight, Auto-homing in Emergency, Navigation, Automatic/Manual Flight
Features
-Unmanned Technology of CTLS (*CTLS : 2 Sits LSA Level)
-Full Autonomous Flight, Navigation
-Payload : Over 60kg
-Real Time Data Transmission
-Wide Coverage for Surveillance & Reconnaissance
Specifications
Size 8.6m(W) / 6.6m(L) / 2.34m(H)
MTOW 600kg
Flight Time 24 hrs
Speed Crusing Speed 185kph(Vc) / 222kph(VH)
Range More than 100Km (Option : Satellite 500Km)
Configuration Vehicle / GCS / Payload
CommunicationC-Band Communication (10Mbps)
Video 720P HD(EO)
Payload 3-Axis Stabilization Gimbal (EO/IR)
