Pallet washing tunnel

for boxes

Two row unit to clean: crates, low crates, chip baskets. Crates charged manually on movable chains are hitched and moved along the washing chamber through: initial washing zone, main washing zone with hot water and detergent, washing down with clean water section and drying section. Clean water is filling up the main tank from clean water sprinklers, through float valve and detergent batcher. In lower unit part are installed two water tanks with rotating drum filters which are cleaning processed water.In the main tank is installed set of heaters which are turning on if water temperature is too low (automatic regulation system). Water pumps are working in water closed circle system and pump water through two rotating drum filters to initial and main washing section through water sprinklers. In final washing zone crates are sprinkled with clean fresh water and dried using air turbine. Infinitely variable regulation of the width and height of the washing channel – adjusting to crate dimensions. Washing chamber covered. Automatic detergent batcher - in accordance with water usage. Made from stainless steel AISI 304.
