BK7 mirror UMLM series

fused silicalaserhigh-reflectivity

High Power Grade Laser Mirror Laser Line Mirrors are used for beam-steering in demanding laser applications. Laser Line Mirrors are Optical Mirrors that have been designed for specific laser types or wavelengths. Product Origin:China Shipping Port:Fuzhou China Lead Time:4 working weeks Payment:T/T Payment, Western Union 1. What UNI Optics can offer for you? The typical Specifications of Laser Mirror we can do are as follows: Specifications: Substrate Materials: N-BK7, Fused silica, Pyrex； Dimensional tolerance: +/-0.1mm Surface quality: 20-10 Parallelism: 1’ Flatness: λ/8 per 25mm@633nm Bevel: Protective One surface: Laser grade Polished and HR coating The other surface: Fine ground Angle of incident: 0° or 45° 2. What are the key features of Laser Mirror? UNI Optics can produce the laser mirror with the following features: Specified wavelength applications High precision High reflectivity High damage threshold 3. Which wavelength can UNI Optics provide? UNI Optics can offer the Laser Mirror with 355nm, 532nm, 1064nm, 1047nm, 1053n. Others can be available according to customers’ requirements.
