Digital clamp meter UT205A+
portable1000 Acat III

Digital clamp meter - UT205A+ - UNI-TREND TECHNOLOGY (CHINA) CO., LTD. - portable / 1000 A / cat III
Digital clamp meter - UT205A+ - UNI-TREND TECHNOLOGY (CHINA) CO., LTD. - portable / 1000 A / cat III
Digital clamp meter - UT205A+ - UNI-TREND TECHNOLOGY (CHINA) CO., LTD. - portable / 1000 A / cat III - image - 2
Digital clamp meter - UT205A+ - UNI-TREND TECHNOLOGY (CHINA) CO., LTD. - portable / 1000 A / cat III - image - 3
Digital clamp meter - UT205A+ - UNI-TREND TECHNOLOGY (CHINA) CO., LTD. - portable / 1000 A / cat III - image - 4
Digital clamp meter - UT205A+ - UNI-TREND TECHNOLOGY (CHINA) CO., LTD. - portable / 1000 A / cat III - image - 5
Digital clamp meter - UT205A+ - UNI-TREND TECHNOLOGY (CHINA) CO., LTD. - portable / 1000 A / cat III - image - 6
Add to favorites
Compare this product


Characteristics

Display
digital
Form
portable
Max current
1000 A
Safety rating
cat III, cat II
Additional features
frequency
Power supply
AA LR6 batteries
Other characteristics
AC, AC/DC
Max DC voltage

1,000 V

Max AC voltage

1,000 V

Max DC current

600 A

Max AC current

1,000 A

Max resistance measure

40,000 kOhm, 60,000 kOhm

Max capacity measure

40 mF, 60 mF

Max frequency measure

10 Hz

DC voltage precision

0.7 %

AC voltage precision

1 %

DC current precision

5 %

AC current precision

1.5 %

Resistance precision

0.8 %

Process temperature

Min.: -40 °C
(-40 °F)

Max.: 1,000 °C
(1,832 °F)

Description

UT205A+/UT206A+ 1000A AC clamp meters are reliable and portable tools for electronics and electrical maintenance. Featuring a lightweight and slim design, and backlight for working in dark environments. These meters also feature duty cycle, NCV, MAX/MIN, and Inrush current measurement. Features of UT205A+/UT206A+ 1000A Digital Clamp Meters ● 1000A AC current measurement ● 1000V AC/DC voltage measurement ● 600A inrush current measurement (UT206A+) ● Temperature (UT206A+) ● NCV (UT206A+) ● ACV frequency 10Hz~10kHz ● Jaw opening: 45mm ● Resistance / capacitance / frequency measurement ● Auto range / backlight / low battery indication ● Continuity / diode / duty cycle ● MAX/MIN ● Data hold / flashlight / relative mode ● Auto power off ● CAT II 1000V/CAT III 600V General Characteristics Power - AAA 1.5V x 2 Standard accessories - Test leads, batteries, temperature probe(UT206A+), English manual Product color - Red+Gray Product net weight - 235g (Including batteries) Product size - 242×76.5x52mm Standard individual packing - Gift box,carrying bag Standard quantity per carton - 20 pcs Standard carton measurement - 420*290*280mm
