Ultra-thin beam splitter UTB series

Beamsplitter is used to divide energy of beam into different portions. Union Optic offer many types of beamsplitters, include Beamsplitter Plate, Nd:YAG Laser Beamsplitter Plate, Ultra Thin Beamsplitter Plate, Non-Polarizing Beamsplitter Plate, Beamsplitter Cube, Non-Polarizing Beamsplitter Cube, Polarization Beamsplitter Cube, Lateral Displacement Beamsplitter and etc. Minimize Beam Displacement Eliminate Ghost Image Easy to Handle With Mount Custom Size Available Specifications: Material BK7 Dimension Mount Diameter 25.4+0.0/-0.2mm Thickness 6.0±0.2mm for Mount, 0.3±0.05mm for Beamsplitter plate Beam Displacement 0.1mm Clear Aperture 18mm Surface Quality 60/40 scratch and dig Parallelism <5 arc minutes Transmitted Wavefront Distortion <λ/10@632.8nm T/R 50/50±5%, for natural light T=(Ts+Tp)/2, R=(Rs+Rp)/2 Coating(AOI=45deg) S1: Partial reflectance coating S2: AR coating
