Pellin-Broca prism PPB seriesfused silicaBK7
Add to favorites
Compare this product
Characteristics
- Type
- Pellin-Broca
- Material
- fused silica, BK7
Description
Pellin Broca Prism is always used to separate the harmonics of laser beam, it can be also used to compensate for group velocity dispersion. Due to the beam enters and exits the prism at Brewster's angle, the power loss is extremely low for P-polarized beam. The angle between input and output beam is close to 90deg.
Specifications:
Material BK7, UV Fused Silica
Dimension Tolerance ±0.2mm
Clear Aperture >90%
Angle Tolerance <3 arc minutes
Surface Quality 40/20 scratch and dig
Flatness <λ/8@632.8nm
Chamfer Protective
Coating None
