Multi-channel manifold DPM series

modular

Deltapoint® Manifold is a modular designed unit that detects leaks from cap loss, hose burst or inadvertent shutoff. Monitoring of robotic cells, pedestal welders or multiple work cells. No need to interrupt plumbing to replace unit. Water is shut down to stop the leak and a signal is sent to the controller. Available with WET (Water Extraction Technology) cap change vacuum system Two ¾ inch ports used to connect to the supply and return cooling water header. Top or bottom feed Four ½ inch ports (two supply & two return) to connect the gun and transformer Two ports for gun cap loss leak detection Two ports for transformer water flow Temperature sensors available for gun and transformer Stand-alone package for installation ease Sensor has no moving parts to wear, break or cause nuisance tripping Visual flow indication reads in GPM or LPM Visual temperature indication reads in degrees F or C User programmable: Leak rate alarm, response time, restart delay, flow OK level, temperature fault level and minimum flow monitoring Bypass - Electrical & Mechanical Available Versions: DeviceNet, Ethernet and Profinet Water/Glycol coolant up to 20% mix US Patent No. 10,641,406
