Stationary thickness gauge MTL series
metalautomatic calibrationonline

stationary thickness gauge
stationary thickness gauge
stationary thickness gauge
stationary thickness gauge
stationary thickness gauge
stationary thickness gauge
Add to favorites
Compare this product


Characteristics

Type
stationary
Applications
metal
Calibration
automatic calibration
Other characteristics
online
Measuring range

Max.: 8 mm
(0.31 in)

Min.: 0.03 mm
(0 in)

Description

Gauge for continuous online contact measuring of metal strip thickness for stamping plants. Type: MTL-501A Process of mesuring: The gauge is lead onto the strip by automatic drive with motor. The measuring head is floating and it compensates the strip motion in the vertical direction and the strip tilt in the direction of its motion. The gauge is furnished with an avaluation unit which digitally displays the on-line measured data and relay outputs. Outputs of the equipment: digital image of the measured thickness 2 relay outputs which signal exceeding the limit thickness data output RS-485 (ASCII, Messbus, Modbus-RTU) Optional accessories: light signalling for exceeding the limit thickness communation interface Profibus analog output visualization software
