UV curing system IntelliRay

for coatingsurface

The IntelliRay is a compact, completely programmable UV flood curing system. All system components of the microprocessor-controlled UV flood curing system are integrated into a small lamp head, which can be easily mounted on the optional Rayven benchtop curing chamber or anywhere on a factory floor, with virtually no cabling or remote power boxes required. Just mount the head, connect the AC line cord, and start timed exposure curing. The system contains an integrated retractable shade type shutter, which allows for repeatable exposure timing and shields the user from UV rays. The system’s LCD display and digital keypad make programming and monitoring of curing operations a snap. The long-life arc lamp and parabolic reflector illuminate an 8 x 6” curing area with evenly distributed UV light. The arc lamp is powered by the state-of-the-art UV Power-Plus Lamp Driver. The head features a convenient carrying handle and a sliding height adjustment bracket. The Uvitron IntelliRay is available in a 400W or higher intensity 600W version. For a larger version of this system, see the IntelliRay Quad. System timers: Duration of curing is controlled by a 1–9,999 second or hour exposure timer that actuates the shutter. The exposure timer also has a user-controlled manual mode and a mode for use in long exposure applications such as artificial aging or solar panel testing. Lamp intensity control: The system has a user-adjustable intensity level. This feature provides the flexibility of choosing appropriate curing intensity for sensitive materials. You can password protect time, intensity and all other settings.
