Parts conveyor system 40 Plus

for asynchronous motorsapplicationsbench-top

The UV Conveyor 40 Plus is a bench-top or stand-mounted UV light curing conveyor system designed for laboratory or high-volume production applications. The conveyor features a quiet variable speed motor with a velocity regulating drive that keeps the belt speed constant for varying loads. The system can be configured with single or dual high intensity lamp heads, which can be removed and reconfigured as stand-mounted systems for increased versatility. The belt-to-lamp height can be easily adjusted from 1.2 to 6.7” for improved compatibility with varying part sizes. The standard conveyor comes with two SunRay lamp heads, and can also be used with our higher power SkyRay LED systems, or with additional sidecure PortaRays for applications requiring full UV coverage. Adjustable lamp height and end chute: Foldaway end covers provide quick access to height adjustment pins, which provide perfectly repeatable settings of lamp head to belt distance. An adjustable position end chute guides accumulating cured parts as they exit the conveyor. Removable lamp heads: The system’s dual lamp heads can be easily removed for bulb replacement and maintenance. They can also be moved quickly from the conveyor to optional low cost shielded mounting stands. This feature allows for offline engineering process testing, and maximum equipment utilization. Dual spectrum capable: The UV Conveyor 40 Plus dual lamp heads offer the unique curing advantage of mixing any of its four available lamp spectrum types. For instance, the UV conveyor’s first lamp head can be fitted with a UVA type whose longer wavelengths penetrate more effectively, providing deeper UV curing.
