Flat vacuum suction cup 10F.025.101.01circularNBRlifting
Add to favorites
Compare this product
Characteristics
- Type
- flat, circular
- Material
- NBR
- Applications
- lifting, handling, for bag opening
- Diameter
25 mm
(0.98 in)
Description
25mm flat blue NBR suction cup with cleats (1002)
General Specifications
Style: Flat
Cleats: Yes
Material: NBR
Thread Size: None
Outside Diameter: 25.0mm
Weight(lbs): .0365
Color: Blue
Lifting Capacity: See Chart
[X] Close
Lifting Capacity for Item 10F.025.101.01
Level of Vacuum (inHg) - Horizontal - Vertical
6"Hg - 0.91 lbs. - 0.45 lbs.
18"Hg - 2.73 lbs. - 1.36 lbs.
27"Hg - 4.10 lbs. - 2.05 lbs.
***Disclaimer: Lifting capacity for handling a non-porous surface. Figures are theoretical and based on 80% of suction cup outside diameter with a 2:1 safety margin for horizontal lifting and a 4:1 safety margin for vertical lifting.
Includes fitting?: NO
