Gate valve

manualstainless steelcompact

Vatac Stainless Steel Gate Valve are designed and manufactured strictly to International Standards API 602, ASME B16.34, DIN3202 or Equivalent, a compact but extremely sturdy design for high pressure-temperature service, Solid CoCr alloy wedge (optional) ensures low friction and long service life, packing rings are precompressed to 4000 psi to provide a high integrity seal, for welded bonnet valves, the bonnet is threaded in and torqued to an engineered torque value and the body bonnet joint is strength-welded, offering double protection against leakage. (Body/bonnet threads and strength-weld), fully guided wedge reduces wear on seating surfaces, Optional design available with double packing, leak-off connection, live-loading and a packing blowout for easy removal of old packing. Vatac Stainless Steel Gate Valve are with main Features as below: » Size Ranges: 1/2” through 2” » Pressure Ratings: ANSI #150 to 2500 » Standards compliance: API 602, ASME B16.34, DIN3202 or equivalents » Materials: A182 F304, A182 F316, A182 F304L, A182 F316L, A182 F51 » Ends Connections: Screwed, Welded Ends and Flanged(FF, RF, RTJ) to international standards » OS&Y, Outside Stem and Yoke » Metal-sealed(API Trim # 1, #5, #8, #10 and etc.) » Optional Locking Device or Stem Extension » Optional Bolted Bonnet, Welded Bonnet or Pressure Sealed Bonnet » Optional Direct Mounting to ISO 5211 » Reduce Port
