Road paint striping machine ROADMASTER 20

truck-mounted

VEZOS ROADMASTER 20 road marking truck is ideal solution for municipalities, aviation markings, airport markings, runway markings & highways. The standard setup includes an RM XHD20 module with two fully chromed 10gpm HYDREX 630 PowerMax piston pumps, a double autonomous hydraulic circuit system & TCS cooling technology. A canopy covered rear operation station, allows operators to control the entire system from the main console. Discover our custom build options depending on your requirements. STANDARD SETUP HYDRAULIC PAINT PRESSURE SYSTEM Module RM XHD 20 - 2 Autonomous & complete hydraulic circuit systems - 2 HYDREX 630 PowerMax hydraulic fully chromed piston paint pumps | 10 gpm (x2) @2150 psi - 4 High pressure pump paint filters - TCS system cooling technology - 55 HP Diesel engine PAINT STORAGE - 2 Drum holders 55 gal each PAINT LOADING SYSTEM - 2 SST Hydraulic paint loading pumps 1 1/2" complete with hosing GLASS BEAD SYSTEM - 1 Carbon steel pressure bead tank 750 lbs. capacity CARRIAGES - 2 Hydraulic gun carriages assemblies with HD pneumatic tires & solenoid boxes - 2 Air lifts - 3 Paint gun actuators Gun configuration: - 2 Automatic airless paint guns + 2 glass bead triggers (left) - 1 Automatic airless paint gun + 1 glass bead trigger (right) - Manual paint | stencil kit (15m hose, manual airless gun, reel) REAR OPERATORS STATION - Canopy deck setup - 2 Rear operator suspension type seat assemblies STD - Operators main control console GUIDANCE SYSTEM - 2 Road marking controllers SKIPLINE USA (up to 4 guns)
