COM Express computer-on-module SOM-6X50
ARM Cortex-A9USB 2.0HDMI

COM Express computer-on-module - SOM-6X50 - VIA Technologies - ARM Cortex-A9 / USB 2.0 / HDMI
COM Express computer-on-module - SOM-6X50 - VIA Technologies - ARM Cortex-A9 / USB 2.0 / HDMI
COM Express computer-on-module - SOM-6X50 - VIA Technologies - ARM Cortex-A9 / USB 2.0 / HDMI - image - 2
COM Express computer-on-module - SOM-6X50 - VIA Technologies - ARM Cortex-A9 / USB 2.0 / HDMI - image - 3
COM Express computer-on-module - SOM-6X50 - VIA Technologies - ARM Cortex-A9 / USB 2.0 / HDMI - image - 4
COM Express computer-on-module - SOM-6X50 - VIA Technologies - ARM Cortex-A9 / USB 2.0 / HDMI - image - 5
COM Express computer-on-module - SOM-6X50 - VIA Technologies - ARM Cortex-A9 / USB 2.0 / HDMI - image - 6
Add to favorites
Compare this product


Characteristics

Form factor
COM Express
Processor
ARM Cortex-A9
Ports
USB 2.0, HDMI
Applications
industrial, medical, military

Description

VIA SOM-6X50 Module The VIA SOM-6X50 module delivers the perfect balance of performance and rich multimedia features in an ultra-compact, highly-flexible package for a wide range of IoT automation and HMI applications such as transportation, retail, and medical. Hardware The ultra-compact VIA SOM-6X50 module measures a mere 6.76cm x 4.3cm, and features 8GB eMMC Flash memory and 512MB DDR3 SDRAM onboard. The module offers rich I/O and display expansion options including three USB 2.0 ports, one HDMI port or one single-channel 18/24-bit LVDS panel, 6 UART, one CSI camera input, 10/100Mbps Ethernet, 9 GPIO, and one SD Card slot.
