Chemical pump 4323AA seriesoilmagnetic-driveself-priming
Add to favorites
Compare this product
Characteristics
- Fluid
- for chemicals, oil
- Operation
- magnetic-drive
- Priming
- self-priming
- Technology
- gear
- Mobility
- stationary
- Domain
- industrial
- Material
- steel
- Protection level
- standard
- Other characteristics
- mechanical, standard, flange, flow, line, seal, jacketed
- Flow
136 m³/h, 248 m³/h, 364 m³/h
(4,802.79467 ft³/h, 8,758.03735 ft³/h, 12,854.53869 ft³/h)- Pressure
9 bar, 14 bar
(130.534 psi, 203.053 psi)- Fluid temperature
Max.: 290 °C
(554 °F)Min.: -30 °C
(-22 °F)
Description
The 4323AA Series™ internal gear API pump is the ideal solution for your oil and gas applications due to its reduced risk of leakage, reduced risk of VOC emissions, and reduced risk of corrosion failure.
Features & Benefits
Jacketed bracket with API 682 seal chamber standard
Dual tapered roller-type thrust bearings with 25,000 hour L-10 life standard
DRIVES
P Purchased Gear Reducer Drive
V Drive | V-Belt Drive
MOUNTING
Foot Mount
SEALING
API 682 Cartridge Seal
Mechanical Seals
