Load rotator

electrichydraulic

Industrial dumpes is used for discharge or transfer of materials between containers. Vinca has extensive experience in manufacturing and installation of dumpers which allows us to offer the best technical advice. We manufacture and install turnkey dumpers chosing the necessary protections and safeguards for every situation. Technical data: • - Capacities from 100kg up to 20.000kg. • - Standard flip angle 125 °. • - Size of fork adapted to measures of the container to turn. • - Retention bar or equivalent system for the retention of the container to turn. • - Electrical panel with integrated control buttons in the same box. • - Electrohydraulic power pack. Variable power according to capacity. • - A primer grey RAL-7037. Optional: • - Side protections on deploye metal grid. • - Access door by the loading side. • - Photoelectric detection by the load side. • - Hopper to the discharge side. • - Cable with control pendant (length to be determined). • - Version with double acting cylinders for greater turning angle. • - Finished in RAL color to be chosen by customer.
