Globe valve 9515/9516 series
manualregulatingdouble

Globe valve - 9515/9516 series - VIR - manual / regulating / double
Globe valve - 9515/9516 series - VIR - manual / regulating / double
Add to favorites
Compare this product

Characteristics

Type
globe
Operation
manual
Function
regulating
Body
double, brass
Associated function
balancing
Other characteristics
DZR, pressure-independent
DN

15 mm, 22 mm
(0.591 in, 0.866 in)

Pressure

16 bar, 25 bar
(232.1 psi, 362.6 psi)

Temperature

Max.: 130 °C
(266 °F)

Min.: -10 °C
(14 °F)

Description

Fixed orifice DZR brass double regulating valveDiameters from DN015 - ½" to DN050 - 2"Threaded F/F (ISO 228/1 for DN15 and DN20, ISO 7/1 Rp above)Olive & nut kit (O/N) for European copper tubing (EN1057) on request: ● DN015, kit for 15 mm pipe ● DN020, kit for 22 mm pipeDesign according to BS7350Tolerance on nominal Kvs ±3% (test according to BS7350)Available in the following versions: ● Fig. 9515, with test points ● Not suitable for: gases group 1 & 2, liquids group 1 (Dir. 2014/68/UE)
