Globe valve 9655 series
manualfor controlregulating

globe valve
globe valve
Add to favorites
Compare this product


Characteristics

Type
globe
Operation
manual
Function
for control, regulating
Body
cast iron, cast iron, copper
Associated function
balancing
DN

Max.: 150 mm
(5.906 in)

Min.: 65 mm
(2.559 in)

Pressure

16 bar
(232.1 psi)

Temperature

Max.: 110 °C
(230 °F)

Min.: -10 °C
(14 °F)

Description

Cast iron differential pressure balancing valve Additional information Material - Cast Iron Typology - Dynamic balancing Connection - Flanged Cast Iron differential pressure control valve Flanged PN16 according to EN1092-2 (ex DIN2533) Available in the following versions: ● For regulating ∆P range 20-80kPa from DN65 to DN150 ● For regulating ∆P range 80-160kPa from DN65 to DN100 Tolerance on nominal ∆P ±10% With copper capillary tube, diameter 4mm, length 2m Test points and joints included TR CU 010 compliant Free of CE marking (cat. according to Art. 4.3 Dir. 2014/68/EU) Working conditions (Ethylene glycol or propylene glycol mixtures up to 50% may be used) ● Not suitable for: gases group 1 & 2, liquids group 1 (Dir.2014/68/EU)
