Cartridge valve 9900P series
manualfor controlthreaded

cartridge valve
cartridge valve
Add to favorites
Compare this product


Characteristics

Type
cartridge
Operation
manual
Function
for control
Body
threaded, straight, brass
Applications
sheet
Associated function
balancing
Other characteristics
ISO, automatic, DZR
DN

Min.: 15 mm
(0.591 in)

Max.: 50 mm
(1.969 in)

Pressure

25 bar
(362.6 psi)

Temperature

Min.: -10 °C
(14 °F)

Max.: 130 °C
(266 °F)

Description

DZR brass cartridges (Fig. KRR9) and DZR brass straight automatic balancing valves Additional information Material - DZR Brass Typology - Dynamic balancing Connection - ISO 7/1 DZR brass automatic balancing valve With threaded union F/F ends (ISO 7/1 Rp) Wide range of flows available (see cartridges section) Valve bodies interchangeable with 9900V series bodies (please refer to specific technical sheet) TR CU 010 compliant Free of CE marking (cat. according to Art. 4.3 Dir. 2014/68/EU) Working conditions (Glycolic-Ethylene and glycolic-propylene mixtures up to 50% may be used) ● Not suitable for: gases group 1 & 2, liquids group 1 (Dir. 2014/68/UE) ● Flow range from 0,02l/s to 0,20l/s for DN15 and L-DN20 valves ● Flow range from 0,13l/s to 0,95l/s for H-DN15, DN20 and DN25 valves ● Flow range from 0,31l/s to 2,60l/s for DN32, DN40 and DN50 valves ● Working ∆P depending on selected cartridge
