The pre-sorted material to be chopped is fed into the two shafts whose rotors are moving slowly in opposite directions (therefore dust and noise free). The cutting discs are plugged on the shaft.This process is controlled by an intelligent and innovative PLC. In case the machine is overloaded or foreign objects are in the cutting unit, the rotor stops and moves backward (return overload behaviour and reverse running). The precisely serrated fixed knives make sure the material is shredded with a minimum of power. The fastened wiper element helps to avoid multiple turn coiling and raising of the material to be chopped.
The number of the knives or their width respectively determines the size of the output material.
Low maintenance
solid construction to be bolted together in the add-on system
Two gear system
therefore constant torque mode on both shafts
User-friendly
innovative PLC with display or touch screen available
Reliable
potent and reliable - the Wagner quality
Failsafe
high availability due to a high quality standard
Easy exchange
knives can be exchanged easily and quickly
Robust design
space-saving
Adjustable
to you specific needs
Equipment
Control panel
user-friendly, high performance and innovative PLC with touch panel
the separately monitored shafts are controllable for maximum throughput
precise rotor current control
10 freely adjustable parameters (operating programmes)
the different operating programmes can be selected quickly by pressing a key
status notification
