Pneumatic lifting device PE 500 / PE 700

multi-product

Cover lifting devices for 30 and 60 liter drums The standardized system components can be configured to create system solutions matched exactly to all your requirements in the field of materials transfer. Basic equipment: pneumatic double- action lifting cylinder including outlet throttling valve, chromed piston rod with attached stop rail, fixing material for holding bracket. Further options such as holding brackets, pneumatic control, drum centering device, base plate must be ordered separately. Do you require complete systems or custom solutions? Please get in touch with us. TECHNICAL DETAILS PE 500 (Lift without attachments) Lift for 30 liter drum cover with lifting cylinder, control unit, cover holding bracket, drum centering, base plate. Drum sizes: Up to 30-liter drums Stroke: 500 mm Max. stroke load: 50 kg Max. op. pressure: 6 bar Max. height*: 1,577 mm PE 700 (Lift without attachments) Drum sizes: Up to 60-liter drums Stroke: 700 mm Max. stroke load: 75 kg Max. op. pressure: 6 bar Max. height*: 1,874 mm
