Diaphragm valve W71 serieshydraulicmix-proofshut-off
Add to favorites
Compare this product
Characteristics
- Type
- diaphragm
- Operation
- hydraulic
- Function
- mix-proof, shut-off
- Body
- double-seat, stainless steel, EPDM
- Associated function
- service
- Other characteristics
- standard
- DN
Max.: 152 mm
(5.984 in)Min.: 38 mm
(1.496 in)- Pressure
7 bar, 10 bar, 10.3 bar
(101.5 psi, 145 psi, 149.4 psi)
Description
Mixproof valves provide safe separation of dissimilar products within the same valve body.
Specifications
For general purpose mixproof applications, we offer the W71 Series for standard shutoff service.
Materials
Product Wetted: Stainless Steel, ASTM 316L (UNS-S31603); (DIN-1.4404)
Non-Product: Stainless Steel, ASTM 304 (UNS-S30400); (DIN-1.4301)
Seat: Tri-Ring Compression Seal on Upper and Lower Stems
Elastomers: EPDM or FKM (Fluoroelastomer)
Finish: ≤ 32 Ra (≤0.8 m) Other finishes available upon request.
