Turntable stretch wrapping machine Uniwrap 300 AE

automaticpalletstretch film

The Uniwrap 300 AE is a fully automatic wrapping machine providing fully automatic pallet wrapping by arm rotation. The Uniwrap 300 AE benefits from the inclusion of a top sheet applicator providing complete pallet waterproofing protection. Description The Uniwrap 300 AE is a robust build stretch wrapping machine made of high quality components delivering reliability in the long term, which minimises maintenance costs. The use of the latest technologies provide total control over the pressure applied by the stretch film over the product, the pre-stretch ratio and the packaging overall holding force. Specification • Throughput: Up to 50 pallets/ hour • Roll Height: 500 ÷ 750 mm • Roll Diameter: Ø 300 mm. max • Internal Roll diameter: Ø 76 mm. • Thickness: 13 -35 micron • Control Panel: Siemens S7 PLC • Colour: Moving parts Orange or Yellow. Fixed Parts: Grey/White, Resida Green or Gentian Blue Benefits • Only one annual service required • Compact, modular system ensuring ease of installation and presents the capability to expand the system further • Requires low headroom • Corrosive resistant paint finish • Soft start and slackening of the rotation of the inverter controlled by the inverter • Adjustable tension of the stretch-film with manual brake on the rubbered roll • Photocell for automatic pallet height detection • Adjustable number of revolutions at the top and bottom of the palletised load • Turntable complete with holes in the front and back of the machine for easy displacement by forklift • Stop of the turntable in fixed position by micro-switch
