Digital temperature control unit WT series

PIDheatingcooling

Water temperature control units, WT...es and WTD...es With closed system for temperature control of water circuits up to 95°C to 140°C. WEINREICH water temperature control units are characterized by service friendliness, simple operation and generous dimensioning of the cooling heat exchangers for power reserve in case of contamination as well as low surface load of the integrated heating rods. Features microprocessor-controlled temperature controller, modular design, with PID behavior and digital setpoint and actual value display alarm contacts, programmable water-bearing parts made of non-corrosive material stainless steel plate heat exchanger as cooling exchanger Stainless steel screw-in heating element integrated in the water flow pipe Safety thermostat with heating current cut-off volume flow/- and system pressure display automatic level monitoring via stainless steel level electrodes automatic water replenishment, optionally from the cooling water line or separate connection dirt trap in the cooling water inlet and separate water make-up feed Options VP reinforced pump performance MK sealless pump with magnetic coupling FU frequency controlled pump SP special voltage versions VK increased cooling capacity VKK limescale-free cooling VA stainless steel versions DA flow display DK direct cooling D steam heated HW hot water heated
