Surface grinding machine PHOENIX

CNCautomaticprecision

The Phoenix ID Grinder is Weldon’s large capacity ID Grinder. The Phoenix can automatically grind diameters, tapers, chamfers, radii, shoulders, and contours in one set-up and one continuous operation using a FANUC CNC control. The Dual Spindle option offers the possibility to grind two different surfaces in one setup or accomplish a rough and finish grind in a single chucking. The grinder can be configured with spindles to best match the diameters that are being ground for the highest possible performance. The addition of a variable speed rotary dresser allows for dressing of both aluminum oxide and superabrasive grinding wheels. - FANUC model 32i BT CNC Control with Color LCD - 160 meters part program storage, 63 PGMS - Shear Damper machine base - Precision cross-roller linear way system - Low inertia break-away coupling, X axis - Automatic Trabon lubrication system - Heavy-duty live spindle workhead, 6A2, #5 MT - Full Enclosure - Air conditioned electrical panel - Work area lighting - Workhead mounted diamond adapter - Coolant plumbing and bed-wash system - Grinding wheel and quill - Set-up tools
