Butterfly valve D371Xwith handwheelpneumaticelectric
Add to favorites
Compare this product
Characteristics
- Type
- butterfly
- Operation
- with handwheel, pneumatic, electric
- Function
- flow control
- Media
- for water, for oil, for liquid food products and beverages, for paint
- Body
- wafer, lug type, small, stainless steel, carbon steel, cast iron, metal
- Applications
- chemical, beverage, for refrigeration, for medical applications, food
- DN
Max.: 800 mm
(31.496 in)Min.: 50 mm
(1.969 in)- Pressure
Max.: 25 bar
(362.6 psi)Min.: 10 bar
(145 psi)
Description
Wafer type butterfly valve has simple structure, small in size, light weight and good flow control features. Can make wafer and lug types, available with soft seal and metal seal for used in different fields such as medicine, paint, environmental protection, refrigeration, oils & fats, brewing, papermaking, biochemical, daily chemicals, food & beverage, water treatment and so on.
Design standard
-
GB/T 12238, API 609, JIS B2071
Face to face
-
GB/T 12221, ASME B16.10, JIS B2002
End Connection
-
GB/T 9113, ASME B16.5, JIS B2211
Inspection and test
-
GB/T 26480, API 598, JIS B2003
