Butterfly valve D71X-16Cmanualflow controlfor wastewater
Add to favorites
Compare this product
Characteristics
- Type
- butterfly
- Operation
- manual
- Function
- flow control
- Media
- for wastewater, for oil, for liquid food products and beverages, for chemical products
- Body
- wafer, seat, lug type, small, stainless steel, carbon steel, cast iron
- Applications
- for the chemical industry, for the food industry, beverage, for refrigeration, for medical applications
- DN
Min.: 50 mm
(1.969 in)Max.: 800 mm
(31.496 in)- Pressure
Min.: 10 bar
(145 psi)Max.: 25 bar
(362.6 psi)
Description
Manual wafer type butterfly valve has simple structure, small in size, light weight and good flow control features. Can make wafer and lug types, available with soft seal and metal seal for used in different fields such as medicine, paint, environmental protection, refrigeration, oils & fats, brewing, papermaking, biochemical, daily chemicals, food & beverage, water treatment and so on.
Trim material
-
304,316,316L
Seat seal material
-
NBR, EPDM, PTFE etc.
Design standard
-
GB/T 12238, API 609, JIS B2071
Face to face
-
GB/T 12221, ASME B16.10, JIS B2002
End Connection
-
GB/T 9113, ASME B16.5, JIS B2211
Inspection and test
-
GB/T 26480, API 598, JIS B2003
Operation device
-
Handle, worm gear, signal, pneumatic,electric actuator
