Ball valve GU-25KFleverfor controlfor liquid food products and beverages
Add to favorites
Compare this product
Characteristics
- Type
- ball
- Operation
- lever
- Function
- for control
- Media
- for liquid food products and beverages, for chemical products
- Body
- flange, weld, stainless steel
- Applications
- for the chemical industry, for the food industry, beverage, vacuum, for the pharmaceutical industry, for the cosmetics industry
- Other characteristics
- ISO, with seal, with tri-clamp connection
- Temperature
Max.: 260 °C
(500 °F)Min.: -30 °C
(-22 °F)
Description
GU series high vacuum ball valve available for manual operation or ISO5211 direct mounting platform apply to pneumatic and electric control, makethe actuator easy installed, and products more beautiful.It has a high flow conductance and the connection characteristics of various forms, used in high vacuum or general pressure conditions.
Widely use in the dairy products, wine, biotechnology, food & beverage, pharmaceutical, chemical, cosmetics and new energy industry, semiconductor industry etc.
Scope Of Application
-
16×105~6.7×10-4Pa(“G” Thread)
6×105~6.7×10-4Pa(Loose Flange)
40×105~6.7×10-4Pa(Weld)
105~6.7×10-4Pa(“KF” Fast Release Flange)
Valve Leakage Rate
-
≤6.7×10-5Pa.L/S.
Installation Status
-
Any
Seal
-
Viton (optional)、PTFE、PPL
