Ball valve GUD-32KFelectricfor liquid food products and beveragesfor chemical products
Add to favorites
Compare this product
Characteristics
- Type
- ball
- Operation
- electric
- Media
- for liquid food products and beverages, for chemical products
- Body
- flange, weld, stainless steel
- Applications
- for the chemical industry, for the food industry, beverage, vacuum, for the pharmaceutical industry, for the cosmetics industry
- Other characteristics
- with bellows seal, high-flow
- Temperature
Max.: 260 °C
(500 °F)Min.: -30 °C
(-22 °F)
Description
GUD series electric high vacuum ball valve operate by electrical device to drive valve ball open or close then turn on or cut off the vacuum flow in the vacuum pipeline. It has a high flow conductance, the connection characteristics of various forms. It can be used in the environment with vacuum or pressure. Widely use in the dairy products, wine, biotechnology, food & beverage, pharmaceutical, chemical, cosmetics and new energy industry, semiconductor industry etc.
Scope Of Application
-
16×105~6.7×10-4Pa(“G” Thread)
6×105~6.7×10-4Pa(Loose Flange)
40×105~6.7×10-4Pa(Weld)
105~6.7×10-4Pa(“KF” Fast Release Flange)
Valve Leakage Rate
-
≤6.7×10-5Pa.L/S.
Installation Status
-
Any
Operating time
-
4s、10s、20s、30s
Power Supply
Generally：AC220V/50HZ
Optional：AC110V、DC24V
Seal
-
Viton (optional)、PTFE、PPL
