Compact nitrogen generator WY-210N-TJ0-KFD49-5

mobilecontainerized

The nitrogen generator container unit is a device that integrates an air compressor, a nitrogen generator, and a nitrogen booster into a standard container, and is used to realize the full function from nitrogen generation to nitrogen pressure boosting. Due to its structural superiority, it is especially suitable for field nitrogen production operations that are frequently transported. Features: Infinitely variable output pressure and flow Holds static pressure without generating heat or consuming power Integrates air compressor, nitrogen generator, and nitrogen booster, compact structure and easy operation; The purity of nitrogen can reach 99.999%; When the set pressure is reached, the equipment automatically stops and is safe to use; Mobile container unit for easy transportation and lifting Technical Parameters Main parameters of air compressor Model: QGF-30/8 Power supply: 380V / 3 phase / 50Hz Power: 30KW Displacement: 4.5m3/min Outlet pressure: 8bar Nitrogen generator main parameters Power supply: 220V/50Hz Power: 0.5KW Air source: 7-10 bar Nitrogen flow rate: ≥5 NM3/h (20°C, 101.325KPa) Nitrogen purity: 99.9 % to 99.9999% Nitrogen pressure: ≤ 5bar (adjustable) Ambient temperature: 0~45°C Air gas tank: volume 0.3m3, pressure level 10bar, safety valve setting pressure 10.5bar Nitrogen gas tank: volume 0.3m3, pressure level 10bar, safety valve setting pressure 8.4bar
