LCD panel PC W12IE3S-VMM9(HB)
LED backlightwith touch screen12"

LCD panel PC - W12IE3S-VMM9(HB) - Winmate, Inc. - LED backlight / with touch screen / 12"
LCD panel PC - W12IE3S-VMM9(HB) - Winmate, Inc. - LED backlight / with touch screen / 12"
LCD panel PC - W12IE3S-VMM9(HB) - Winmate, Inc. - LED backlight / with touch screen / 12" - image - 2
LCD panel PC - W12IE3S-VMM9(HB) - Winmate, Inc. - LED backlight / with touch screen / 12" - image - 3
Add to favorites
Compare this product


Characteristics

Screen type
LCD, LED backlight, with touch screen
Display size
12"
Resolution
1280 x 800
Processor
Intel® Celeron® N6210
Construction
open frame, compact, fanless
Mounting
desktop, stand, vehicle-mount
Applications
industrial, for IoT applications, for data acquisition systems, data acquisition, for mobile applications, POC, for railway
Protection level
vibration-resistant
Other characteristics
multimedia, all-in-one, real-time, EN 50155

Description

W12IE3S-VMM9(HB) 12.1" Intel® Celeron® N6210 G-WIN Vehicle Mount Panel PC KEY FEATURES Intel® Celeron® N6210 Processor 1.5M Cache, up to 2.60 GHz, Fanless Design 5 Wire resistive touch screen Anti-Corrosion housing with Fanless Design WLAN with Antenna (Optional) Anti-Shock & Vibration compliant with MIL-STD-810F/G 10 ~ 60V DC Isolation Wide Range Power Input. Optional Ignition on/off control function. Panel Mount for request Design to meet EN50155 Front IP65 protection against water and dust Winmate front IP65 panel PC is protected against outer dust and water splash and is ideal for harsh environments. Fanless cooling system and ultra-low power consumption G-WIN series adopts a fanless design with passive cooling fins. Reduce noise, and power consumption, boost reliability, and extend the life cycle. Rugged housing with anti-shock and vibration Winmate's G-WIN series panel PCs are designed to pass US Defence standards environment tests. The overall construction of the G-WIN panel is inherently rugged with the aluminum die-cast housing and anti-corrosion to hold up even in exposed settings.
