Stainless steel siphon US 100 series

Stainless steel siphon - US 100 series  - Wisy AG
Stainless steel siphon - US 100 series  - Wisy AG
Stainless steel siphon - US 100 series  - Wisy AG - image - 2
Stainless steel siphon - US 100 series  - Wisy AG - image - 3
Stainless steel siphon - US 100 series  - Wisy AG - image - 4
Stainless steel siphon - US 100 series  - Wisy AG - image - 5
Stainless steel siphon - US 100 series  - Wisy AG - image - 6
Add to favorites
Compare this product


Characteristics

Options
stainless steel

Description

Surface debris removed by skimming effect Prevents storm drain odours from reaching the storage tank Brace pipe prevents tilting or tipping Large siphon volume 6 l (1.5 US gallons) Drain backflow prevention (optional) Vermin guard (optional) Made of impact-resistant ABS plastic. For connection to the tank overflow (DN 100). Surface debris removed by skimming effect. Prevents storm drain odours from reaching the storage tank. Brace pipe prevents tilting or tipping. Large siphon volume 6 l (1.5 US gallons). AVAILABLE IN DIFFERENT VERSIONS: With or without drain backflow prevention With or without vermin guard The version with integrated drain backflow prevention is delivered with a retaining clamp for connection to a DN 100 (3.9 in) pipe. The passive vermin guard is made of stainless steel and is easy to remove for maintenance. HOW TO INSTALL THE MULTISIPHON? The installation of the Multisiphon is very simple, just follow these 2-3 steps: Connect the Multisiphon to the overflow pipe DN 100 Put the brace pipe below into place to prevent tilting or tipping Models with integrated backflow prevention: Use the retaining clamp to secure the connection between Multisiphon and overflow pipe
