Gas non-return valve 339-ES

threadedstainless steelspring

Non-return valve, stainless steel, for the prevention of unintended gas mixtures, for flow rates up to 285,916 scfh (air), up to 232 psi for use in thermal processing plants, certified to EN746-2, G 1.1/2 - G 2 safety element: non-return valve [NV] every non-return valve 100% tested DVGW-approval protects against flashbacks, for fuel gas-compressed air-mixtures ultra-low opening pressures (approx. 0.0435 psi), ultra-low pressure drop ideal for biogas desulphurization systems also ideal for use with corrosive gases dirt filter (100 μm) on gas inlet 3.51 X 5.66 inches, 105.32-106.6 oz WITT non-return valves (check valves) for reliable protection against dangerous reverse gas flow. Every non-return valve (check valve) 100% tested. Benefits: a spring-loaded non-return valve (check valve) prevents a reverse flow of gases which could lead to unwanted gas mixtures low pressure drops – using complex valve assembly with low opening pressures no leaks – using a spring-loaded valve assembly with elastomer sealing stainless steel filter (100 μm) in the gas inlet protects the non-return valve against dirt contamination, extending the service life diverse applications – useful for many technical gases Operation / Usage: non-return valves (check valves) are used to protect equipment and pipelines against dangerous reverse gas flow. Use is possible for applications according to EN 746-2 ideal for use with corrosive gases in the chemical industry, process technology or in laboritories WITT non-return valves (check valves) may be mounted in any position / orientation the maximum ambient / working temperature is 70 °C / 158 °F
