Hybrid motor starter 36125

electronic3-poleAC

hybrid motor starter, 3-pole direct and reversing starter 0.18 - 3.0 A / switch for resistive loads 0.18 - 3.0 A with IO-Link interface, with CrossLink®Technology for busbars 12, 15, 20, 25, 30 x 5, 10 and section busbars NEW System 60Classic Product group - 21 Subgroup - 09 pack size - 1 EAN - 4021267361259 Advantages of the product 4 functions integrated: Right contactor Left contactor Motor protection relay Installed width only 22.5mm 30 million electrical switching operations catalog page - 2020 : 3.16 eCl@ss 6.1 - 27370804 eCl@ss 7.1 - 27370804 ETIM 4.0 - EC001037 ETIM 5.0 - EC001037 Details IEC Standards IEC 60947-1:2007 + A1:2010 + A2:2014 IEC 60947-4-2:2011 IEC 61508-1:2010 ISO 13849-1:2015 Electrical data IEC Rated current (IEC): - 3 A rated voltage (IEC) AC: - 500 V min. operating voltage AC: - 42 V set nominal current: - Yes min. load current: - 0.18 A max. switching frequency: - 2 Hz switching cycles: - 30.000.000 rated frequency (IEC): - 50 / 60 Hz rated isolation voltage Ui AC: - 550 V rated surge voltage Uimp : - 6 kV power dissipation of the article: The power dissipation at a typical load of 80 % results to 3.8 W. (The power dissipation at full load would be 6 W.)
