Cyclone separator Woz-X

wateroilstainless steel

Woz-X Separators are designed to remove oil and vapour mist drawn through extract ventilation ducts, primarily serving shale shakers and mud tank/mud pit areas, thus protecting operators, equipment and the environment. The Woz-X Separator utilises patented Reven® separator panels. A single stage separator can be installed into existing extract systems or designed for new applications. Where very high levels of oil and mist separation are required a three stage separator is also available and, if required, the Woz-X Separator can be packaged with extract fans. Maximum Size No maximum size Materials Stainless Steel 304L/316L (1.4307/1.4404) X-cyclone panel only available in SS304 Thickness Minimum 3.0 mm/ 5.0 mm Fully welded Flange drilling detail to ISO 15138 or Client standard
