Air filter Veotec Multiple Stage

panelfor HVACintake

This multiple stage moisture eliminator is the SE2 combined with bag type filters to achieve efficiencies to client specifications, but typically F7 – F9 for HVAC intakes, up to H10 – H12 for gas turbine intakes. By combining the filtration into one package there can be a considerable space saving and easier maintenance access. The filter holding frames are manufactured to provide a very cost effective method of refurbishing an existing system. For example, to replace a current Single Stage intake system with a Multi Stage intake system offering a higher level of protection in the same space. Materials Casing and Flanges Stainless Steel 304L/316L (1.4307/1.4404) Aluminium 5083 Materials SE Profile Vane Stainless Steel 304L/316L (1.4307/1.4404) Aluminium 6063 T6 Acrylonitrile styrene acrylate (ASA) Rigid Polyvinyl Chloride (RPVC)
