Butterfly valve T1, T2pneumatically-operatedelectrically-actuatedfor control
Add to favorites
Compare this product
Characteristics
- Type
- butterfly
- Operation
- pneumatically-operated, electrically-actuated
- Function
- for control
- Media
- for gas
- Applications
- liquids
- Other characteristics
- ANSI
- DN
Max.: 500 mm
(19.685 in)Min.: 25 mm
(0.984 in)- Pressure
Max.: 6.3 bar
(91.4 psi)Min.: 1.6 bar
(23.2 psi)- Temperature
Max.: 650 °C
(1,202 °F)Min.: -196 °C
(-321 °F)
Description
T1, T2 series three way control valve, the use of fluid pressure balanced valve core form and the top of the valve structure, in which the T1 series are flow splitting valve, while T2 series are flow mixing valve. Suitable for gas and liquid medium without solid particles.
The actuator for T1, T2 series three way valve can be QLM series sliding pneumatic type or EML series electric type.
T1, T2 series are also available with bonnet extension type, bellows seal type and jacket type.
Body material
WCB, CF8, CF8M, CF3M
Leakage class
ANSI Ⅳ or Ⅴ
Cv
6.3~4000
