Radar level sensor GLT508
for waterdigital outputwireless

radar level sensor
radar level sensor
Add to favorites
Compare this product


Characteristics

Technology
radar
Medium
for water
Interface
digital output, wireless
Other characteristics
stainless steel, IP67
Process pressure

Max.: 19.61 bar
(284.42 psi)

Min.: 0 bar
(0 psi)

Process temperature

Max.: 70 °C
(158 °F)

Min.: -20 °C
(-4 °F)

Description

GPRS network available in many application areas with mobile signal LCD real-time display with backlight Ultra-low power consumption and sleeping mode lower to 15uA@12V DC Networking automatic time checking and offline automatic connection Remote setting for collection and transmission interval Alarming function for upper and lower limit of threshold value and remote setting for threshold value PC and mobile terminal data application GLT508 is an intelligent instrument with low power consumption and wireless communication function. With a core of advanced industrial MCU and a high quality level sensor, it integrates the mature GPRS network to realize the wireless transmission between field sensors data and server. GLT508 reports the data actively based on the set interval and the customer could realize the remote instrument configuration and data checking through WEB pages. All the uploaded and transmitted data will be stored into database automatically for the convenience of further checking. Users could log in related URL by networked PC or Mobile Terminal to get data and meanwhile to do statistics and analysis for the data, then forming a report and data graph, which is featured as visual, accurate and high-efficient. Based on widely covered GPRS network, the product could detect real-time data of many monitoring sites within a large areas like water tank level and hydro-logic monitoring. application: It is mainly used in fields like tap-water plant and hydroelectric power plant.

Catalogs

GLT508
GLT508
3 Pages
