Plug-in terminal block HFLS1C seriesscrew connectionfor testingIEC
Add to favorites
Compare this product
Characteristics
- Mounting
- plug-in
- Connection
- screw connection
- Applications
- for testing
- Other characteristics
- IEC, insulated
- Cross-section
Min.: 0.2 mm²
(0 in²)Max.: 2.5 mm²
(0 in²)- Current
8 A, 10 A, 12 A
- Nominal voltage
250 V, 300 V
Description
● Spring-based fast link technology
● Easy to connect and divide wire terminal using screw
● With test hole, can plug in test needles with diameter of 1mm or 2mm, and test plug with diameter of 1.0mm or 1.2mm
Detailed parameters
Poles - 2~16
Pitch - 3.81mm
Rated Dielectric Strength - 1500Vac/min
Rated Withstand Pulse Voltage - 2.5kV
Ambient Temperature - -40℃~105℃
Striping Length - 9mm
Insulation Material Type/Insulation Material Group PA/I
HFLS1C-381
Features
● Spring-based fast link technology
● Easy to connect and divide wire terminal using screw
● With test hole, can plug in test needles with diameter of 1mm or 2mm, and test plug with diameter of 1.0mm or 1.2mm
Detailed parameters
Poles - 2~16
Pitch - 3.81mm
Rated Dielectric Strength - 1500Vac/min
Rated Withstand Pulse Voltage - 2.5kV
Ambient Temperature - -40℃~105℃
Striping Length - 9mm
Insulation Material Type/Insulation Material Group PA/I
