MOV varistor SFV7D series
for electronics

MOV varistor
MOV varistor
Add to favorites
Compare this product


Characteristics

Options
MOV, for electronics
VAC

Max.: 510 V

Min.: 14 V

VDC

Max.: 670 V

Min.: 18 V

Primary current

Max.: 1,750 A

Min.: 500 A

Description

Metal Oxide Varistor (MOV) as one nonlinear resistance element is mainly made of zinc oxide (ZnO), which has very high surge capacity and big nonlinear coefficient. Below the threshold voltage, its resistance is very high, nearly no current flows through, but above the threshold voltage, the resistance reduces sharply, huge current can be discharged. Due to this characteristic, varistor as a protection component in electronic and electrical equipment can absorb abnormal over-voltage and lightning surge. SETsafe | SETfuse varistor is with High Surge Current Density, Low Clamping Voltage, and Good Surge Capacity. It can also be customized as required. ● Epoxy Resin Coating ● Silicone Resin Coating ● Low Leakage Current ● Bidirectional and Symmetrical V/I Characteristics ● Operating Temperature Range: Low Temperature: -40 °C, High Temperature: 85 °C / 105 °C ● RoHS & REACH Compliant Mounting Style Through Hole Termination Style Radial ● Power Supplies ● Home Electrical Appliances ● Industrial Devices ● Surge Protectors ● Telecom Devices
