NBR seal RB series

for motors

10*24*3.5 Rb/GAMMA Type Iron Dust Seal for Motor Gamma seals happen when the axial force of the lip comes into contact with the housing.The metal parts protects the rubber axial lip form exernal pollution. 10*24*3.5 Rb Type Iron Dust Seal for Motor The design of GAMMA seal TRB/9RB is based on many years of experience, the sealing lip total axial pressing force depends on the pre elongation of the rubber body, and sealing lip elasticity and deformation, and the sealing lip deformation depends on the sealing lip with respect to the friction surface assembly location. The metal case protects the seal against the hard object and plays the other polluting medium by centrifugal force, and has a good drain capacity after dipping the liquid. The shape of the metal shell creates an additional dust barrier through the installation of the labyrinth in the groove, which is very effective for heavy use. Item - RB type dust proof oil seal Size - 10*24*3.5 Structure - a metal bracket protects the elastomer seals, mainly blocking the entry of outside contaminants Properties - temperature -40ºC to +200ºC; higher than 20m/s; used for rotation Features - fixed shaft, with the axis of rotation, through the bore to locate Pressure - no pressure Medium - mineral oil and synthetic lubricants (CLP, HLP, APGL, etc.) Housing - carbon steel + galvanized (stainless steel and acid resistant steel as required) Advantage: The good dynamic sealing The good protection, to prevent pollution of solid particles The new lip design, the axial force is very small (less power loss) The installation of a narrow width I don't need another fixed It is very effective with labyrinth seal
