Ball valve
pneumatichydraulicfor water

Ball valve - Yantai Jereh - pneumatic / hydraulic / for water
Ball valve - Yantai Jereh - pneumatic / hydraulic / for water
Add to favorites
Compare this product


Characteristics

Type
ball
Operation
pneumatic, hydraulic
Media
for water, for oil, for acids, for gas
Body
manifold, symmetrical
Applications
for water, actuator
Associated function
balancing
Other characteristics
remote control
DN

9 in

Pressure

Min.: 5,000 psi

Max.: 20,000 psi

Temperature

Min.: -75 °F
(-59 °C)

Max.: 250 °F
(121 °C)

Description

Jereh frac valves are developed to meet continuous high pressure and large displacement demand. The valve is installed on frac tree or frac manifold, with a balancing lower stem on the bottom and a unique ball screw structure, featuring low torque and easy operation. Features Full-bore, two-way symmetrical downstream seal, pressure assisted seal Two lubrication fittings for washout and lubrication of valve chamber Proper gap between gate and seat can block foreign matters and prevent binding. Zero-chamfer flowbores help to mitigate turbulence during fracturing operations. Low open/close torque, only 2/3 of valves of the same size and pressure rating Hard alloy sealing surface and metal seal deliver long service life. Hydraulic/pneumatic actuator realizes remote control.
