Automatic control unit ZPS 2-M

three-phaseprogrammable

polycarbonate switch box for wall mounting displaying of operation modes via clear text display and signal lights automatic operation of one three-phase or mono-phase pump programmable starting delay and follow-up time visual and audible fault signal with potential-free outputs level control by means of dynamic pressure method, float switches or 4 - 20 mA interface for external sensor displaying of operating hours, power consumption and maintenance interval fault memory for last 64 faults Application automatic pump control Technical data Power supply 1~230 V Frequency 50/60 Hz Nominal current 0,3-14 A Width 180 mm Length 254 mm P-dimensions (WxHxL) 230 mm x 260 mm x 380 mm
