Power cable U/UTP

coppersolidIEC

The use of high-quality oxygen-free copper material to ensure excellent tensile properties and resistance properties. The optimized design of high-speed cable pitch technology production process greatly improves crosstalk And the transmission performance index margin such as return loss, etc., to obtain a higher transmission bandwidth. Adopt unique cable structure process design, national patent (CN206672675U) passed 6 pack 1 external interference test. ISO/IEC 11801-1、ISO/IEC 11801-2、IEC 61156-5、 EN 50173-1、EN 50173-2、EN 50288-3-1、 ANSI/TIA-568.2-D、IEC 60332-1-2、IEC 60754-2、 IEC 61034-1、IEC 61034-2 Conductor: Solid bare copper 23AWG Insulation materials: HDPE Insulation diameter: 1.12±0.05 mm Sheath diameter: 7.1±0.5 mm Sheath material: LSZH Working temperature: -30 °C~ 60 °C\ Transmission delay difference: ≤45ns / 100m Transmission speed: 69% DC resistance: ≤ 9.38 Ω/100 m DC resistance unbalance: ≤ 5%
